Ductile Iron Pipe

Product Specifications: DN80-2600
Product Standards:
European Standards: BS EN 545, EN 598
National Standards: GB/T 13295, GB/T 26081
International Standards: ISO 2531, ISO 7186
Product Material: ASTM A536 Grade 65-45-12, GB/T 1348 QT450-10
Gasket Material: EPDM, sanitary performance complies with the drinking water standard GB/T 17219
Implementation Standards: GB/T 27572, GB/T 28604, GB/T 21873

Inquire Now

Product description

Ductile iron pipes are produced by adding a nodulizing agent to molten iron to achieve nodulization, then casting into shape using centrifugal force in a centrifuge. After annealing, these pipes acquire a ferritic matrix structure, commonly referred to as nodular pipes, ductile iron pipes, or simply ductile pipes. The ductile iron pipes from Meide Group significantly outperform those of competitors. With a comprehensive size range from DN80 to DN2600, they strictly adhere to international and national standards, making them suitable for applications in water supply, drainage, and more. Additionally, Meide Group offers full-process technical guidance, efficient logistics distribution, and long-term after-sales tracking services.

Customer challenge

Enhancing the service life of pipeline systems

Although traditional steel pipes have high strength, their corrosion resistance is poor, making them prone to rust and requiring frequent maintenance and replacement, resulting in a shorter service life.

Improving Connection Methods

Traditional welding methods often present significant challenges during construction. Welding requires substantial manpower and time, and the quality of the weld is heavily dependent on the skill level of the operator. This frequently leads to issues where the welding quality fails to meet the required standards.

Product function

Fluid Transport Function

Corrosion Resistance Function

Ductile iron pipes serve as the primary conveyance conduits in water supply and drainage systems, capable of transporting a variety of fluid media. Their stable performance and reliable connection methods ensure the smooth and efficient transport of fluids within the pipeline.

The interior walls of these pipes are lined with anti-corrosion coatings such as cement mortar, while the exterior walls are treated with zinc spraying and additional anti-corrosion coatings (e.g., zinc spray + asphalt paint coating, epoxy coal tar coating, etc.), providing excellent resistance to corrosion.

Value advantage

Strong Sealing Performance

Utilizing a flexible rubber ring interface, the pipes effectively prevent leakage of fluids within the pipeline.
Excellent Hydraulic Performance

The smooth interior walls reduce water flow resistance, and the pipes exhibit good compatibility between diameter and flow rate.
Superior Mechanical Properties

These pipes boast outstanding mechanical properties, including high strength and good toughness, enabling them to withstand a certain degree of external impact without breaking or sustaining damage. This makes them suitable for a variety of complex working conditions.
High-Quality Raw Materials

Made with premium molten iron from Meide Gengchen, ensuring high-quality and reliable material.
Ease of Construction and Installation

With moderate weight, simple interfaces, and flexible joints, these pipes can adapt to certain terrain variations, facilitating easier installation.
Long Service Life

Under normal usage and maintenance conditions, these pipes have a long service life, exceeding fifty years.
